Catalog — Hydraulic Breakers

Hydraulic Breakers for Skid Steers in Canada

Skid steer hydraulic breaker attachments sold in Canada — for concrete demolition, rock breaking, and frost-hardened ground.

Buyer's Guide — Hydraulic Breakers

▲ Collapse
Hydraulic breakers, also called hammers, break concrete, frozen ground, bedrock, and asphalt that buckets cannot penetrate. Impact energy — measured in foot-pounds — must be matched to your machine size and material type. Under-classing wastes time; over-classing wastes hydraulic energy and stresses the carrier. For Canadian operators, frozen ground breaking and concrete demolition are the two primary applications. Light-duty breakers (100–400 ft-lb) suit compact machines for concrete work. Mid-class (400–700 ft-lb) for mid-frame machines on concrete and frost-hardened ground. Heavy (700–1200 ft-lb) for large-frame machines on bedrock and heavy demolition.

Sizing Guide

Size the breaker class to your machine's rated operating capacity. Compact machines (less than 2,500 lb ROC): 100–400 ft-lb class. Mid-frame machines (2,500–3,500 lb ROC): 400–700 ft-lb class. Large-frame machines (3,500+ lb ROC): 700–1,200 ft-lb class. Going significantly larger than the class recommended for your machine strains the carrier and delivers no useful performance gain.

Hydraulic Flow

Most mid-frame skid steer breakers run on standard auxiliary flow (12–22 GPM). Large-class breakers for large-frame machines often require high-flow. The critical spec that's often overlooked is back-pressure: hydraulic breakers are sensitive to return-line back-pressure. Many skid steers run 200–400 PSI back-pressure; most breakers require under 150 PSI. Exceeding back-pressure limits damages the breaker valve — check both GPM and back-pressure tolerance.

Brands in Canada

Atlas Copco (premium, global service network), Okada (strong Canadian dealer presence, reliable for commercial work), Rammer (Finnish quality, premium price), Stanley (widely used in Canadian contractor fleets, solid service network), TMG Industrial (light-duty budget option). For Canadian commercial work, Okada and Stanley offer the best combination of dealer support and price.

⚠ Most Common Mistake

Ignoring back-pressure limits. This is the spec that gets overlooked most often. Many operators assume any standard-flow machine can run any standard-flow breaker — but if the machine's return-line pressure exceeds the breaker's rated back-pressure tolerance, the internal valve seal fails. Check the back-pressure spec, not just GPM.

Hydraulic breakers (also called hammers) break concrete, frozen ground, and bedrock that buckets cannot penetrate. Impact energy is measured in foot-pounds; matching breaker class to machine size matters more than any other spec. Standard-flow machines run light-duty breakers; large-frame machines run 700–1200 ft-lb models. All products listed here are available in Canada.

Where to startSelect breaker impact class based on your machine size and material — overpowering a breaker wastes hydraulic energy; underpowering wastes time.
How to choose

Hydraulic Breakers — 56 Products

Bobcat Cat Epiroc Gehl HLA Attachments IronBull JCB John Deere New Holland NPK Rammer Skid Pro Takeuchi TMG Industrial Virnig Werk-Brau Atlas Copco Berlon Blue Diamond Case CE HLA Kubota Paladin Attachments
